| Model | CS-03M |
| Type | 6.5" Full-range Ceiling Speaker |
| Driver | 6.5" |
| Power Handling(AES) | 3W |
| Input Power | 100V | 3/2/1W |
| 70V | - |
| Impedance | 100V | 3.3k/5k/10kΩ |
| 70V | - |
| LOW | - |
| Power Selection | By Wiring |
| Frequency Response(-10dB) | 300Hz ~ 14kHz |
| Frequency Range(-20%) | 120Hz ~ 17.7kHz |
| Sensitivity (1W/1m, 1kHz) | 90dB |
| Maximum SPL[Cont] | 95dB |
| Nominal Dispersion(Conical) | 1kHz | 160˚ |
| 4kHz | 60˚ |
| Input connection | Bi-Wired |
| Enclosure Material | Aluminum |
| Enclosure Color(Front) | White |
| Grille Material | Metal Grille |
| Grille Color | LIGHT BLUE |
| Cut-Out Diameter(Ø, mm) | Ø195 ~ 200 |
| Weight (Net) | 900g |
| Dimensions (Ø(WxH)xD, mm) | Ø228 x 96 |
| Weather Resistant | - |
| Flame resistant | ○ |
| Certification | - |
| Included Accessories | - |
